Ātrā savienojuma savienotājs 0,5-1mm2 10A 5gab blisteros (02340)

A quick-connect terminal is an electrical connector designed for the quick and safe connection of insulated wires;

Simply press the insulated wires into the metal insert, snap the cover into place and squeeze with a standard pair of pliers; then attach the connector to the terminal, creating a ‘branch’ from the connection.

Once the connection has been made correctly, the wires are crimped into the metal connector to form a permanent connection, and an additional load can be connected to the connector.

Quick-connect terminals are products designed for low-voltage installations (12–24 V) and are most commonly used in the automotive industry.

Quick-connect terminals are designed for the rapid connection of wires.

Specification:

• max 10A
• wire cross-section: 0.5 to 1 mm²
• -50°C to +105°C
• PVC insulation

Installation:

• Insert both wires into the connector.
• Press the metal insert into place using pliers.
• Snap the cover into place.

Note: The installation does not require the insulation to be stripped from the wires.
