TP-Link CPE510 Беспроводная точка доступа (Access Point) N300 / 2x RJ45 100Mb/s / 13dBi (TL-CPE510)

Multifunctional external device

TP-Link CPE510 is a multifunctional external device that can work as an access point, Client, bridge, repeater, AP router and WISP. It is equipped with a MIMO 2x2 directional antenna with 13 dBi power and a central Pharos Control management system. The system is optimized for long-distance transmission.
A Passive PoE adapter is included, allowing the device to be powered over a maximum distance of 60 meters.

Wide range of applications

CPE 5 GHz 300 Mb/s provides effective solutions for external wireless networks. Thanks to the central management system it is ideal for point-to-point and point-to-multipoint Wi-Fi connections. Professional performance combined with ease of use makes CPE510 a great choice for both business customers and individual users.

Quality and durability

Thanks to Qualcomm Atheros chipsets, high gain antennas, high quality materials, specially designed housing and PoE power supply, the presented CPE510 can operate in virtually any conditions, within the temperature range from -40°C (-40°F) to +70°C (158°F).

Wireless transmission over 15 km

Specially designed for outdoor applications CPE510 allows wireless transmission over a distance of more than 15 km.

TP-LINK MAXtream TDMA technology

To prevent lowering network bandwidth and collisions between other transmitters, the CPE510 uses TP-LINK MAXtream TDMA technology.

Pharos Control - central management system

Pharos Control is software that allows you to manage all CPE510 access points in your network from a single computer. With Pharos Control, numerous functions such as device detection, status monitor, software updates and network management can be used remotely.

Specification:

Operating frequency : 5 GHz
AC input frequency : 50/60
AC input voltage : 100 - 240
Antenna direction type : Omni-directional
Antenna features : Integrated antenna
Antenna gain : 11dBi - 20dBi
Antenna gain level (max) : 13
Antenna type : Internal
Antennas quantity : 1
Automatic channel scanning : Yes
Automatic channel selection : Yes
Bandwidth : 5
Built-in processor : Yes
Cables included : AC
Cabling technology : 10/100Base-T(X)
Certification : - FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark - RoHS
Compatible operating systems : Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Device type : Client device
Ethernet LAN (RJ-45) ports : 1
Ethernet LAN data rates : 10,100
Flash memory : 8
Frequency band : 5.15 - 5.85
Housing material : Plastic
Input current : 0.8
Internal memory : 64
International Protection (IP) code : IP5X
IP address filtering : Yes
LED indicators : Yes
MAC address filtering : Yes
Management platform : Pharos Control
Management protocols : TDMA
Maximum data transfer rate : 300
Maximum outdoor range : 15000
Networking standards : IEEE 802.11a,IEEE 802.11n
Operating relative humidity (H-H) : 10 - 90
Operating temperature (T-T) : -30 - 70
Power consumption (typical) : 13
Power over Ethernet (PoE) : Yes
Processor architecture : MIPS 74Kc
Processor frequency : 560
Processor model : Qualcomm Atheros
Product colour : White
Receiver sensitivity : 802.11a
Reset button : Yes
Security algorithms : 128-bit WEP,152-bit WEP,64-bit WEP,TKIP,WPA,WPA-PSK,WPA2,WPA2-PSK
Storage relative humidity (H-H) : 5 - 95
Storage temperature (T-T) : -40 - 70
Throughput data rate : 300
WAN connection : Ethernet (RJ-45)
Web-based management : Yes
